1/Servo technology, to improve the stability of the machine, to reduce the normal gear caused by wear
2/The casting machine, ensure the machine stability
3/No shaft, no gear, a variety of design of the whole servo drive, To meet the different requirements of customers
4/Servo drive, printing more widely, Can be used for all kinds of materials
5/No gear drive design, to get rid of 1/8 inch (3.175mm) pitch limit, avoid gear ink
6/Servo control to ensure the transverse and longitudinal ability
7/Using the closed-loop tension control, ensure the stable tension
8/Standard supporting automatic correction, provide continuous printing material deviation control
9/The control panel is easy to use, automatic operation: display interface, operation data stick out a mile
10/Equipped with fault diagnosis function, helping the user to eliminate fault quickly
11/Configurable automatic non-stop reeling device
12/Configurable remote communication, remote control
FM-CS1020-1350 Flexographic Printing Machine(Petal Type)
- Petal type plate mounting, anilox and cylinder with quick change structure.
- Printing unit easy operation, cylinder and anilox pressing once successfuly.
- Plate full servo shaftless transmission, automatically pre-print, time saving & material saving.
- Registering remains the same during lifting process.
- Register position automatic memory function.
Application Object
Suitable for eco-friendly packaging, such as the paper bag used for food and healthcare industry, paper box, paper cup, the pre-printing carton of paper bag, bag courier, milk carton medicine use.
Paper Used
Kraft paper, paperboard, coated paper, liner paper, laminated paper, multilayer composite paper, carton board materials ect.
Technical Parameters:
| Specification | 1020 | 1300 | 1350 |
| Max. Web Width | 1020mm | 1300mm | 1350mm |
| Max. Printing Width | 1000mm | 1270mm | 1320mm |
| Max Die-Cutting Width | 1000mm | 1270mm | 1320mm |
| Printing Repeat | 300-1200mm | 300-1200mm | 300-1200mm |
| Die-cutting Repeat | 300-1200mm | 300-1200mm | 300-1200mm |
| Max.Unwinder Diameter | 1524mm | 1524mm | 1524mm |
| Max.Rewinder Diameter | 1524mm | 1524mm | 1524mm |
| Gearing | 1/8cp | 1/8cp | 1/8cp |
| Max Printing Speed | 240m/min | 240m/min | 240m/min |
| Diameter of web roller | 100mm | 100mm | 100mm |
| Drying mode | Warm Drying/IR Drying/ UV Drying |
| Substrate | 80-450g chrome paper, aluminum-foil paper, BOPP, PET, paper board, kraft paper. |
